• External dimensions: 4,100mm long, 1,690mm wide, 1,550mm high, 2,600mm wheelbase, 1,470mm front track, 1,460mm rear track, 11,000mm turning circle (kerb to kerb), 161.4 inches long, 66.5 inches wide, 61.0 inches high, 102.4 inch wheelbase, 57.9 inch front track, 57.5 inch rear track and 36.1 foot turning circle (kerb to kerb)
• Internal dimensions:

• Load compartment capacity: 437 litres with rear seats up filled to lower edge of window, 1,332 litres with rear seats down filled to ceiling, 15.4 cu ft with rear seats up filled to lower edge of window and 47.0 cu ft with rear seats down filled to ceiling
• 46 litre, 10.1 UK gallon main fuel tank

• Weights: gross vehicle weight rating (kg): 1,615, gross vehicle weight rating (lbs): 3,560, curb weight (kg): 1,180, curb weight (lbs): 2,601, gross trailer weight braked (kg): 900, gross trailer weight braked (lbs): 1,984, gross trailer weight unbraked (kg): 510 and gross trailer weight unbraked (lbs): 1,124

• Roof aerial
• Body colour side rubbing strip
• Painted front and rear bumpers
• Front fog lights
• Front and rear tyres: 16 inch diameter, 185mm wide, 55% profile, V rated ; Load index: 88 (official data)

• Gloss paint
• Body colour power door mirrors ; heated
• Electrically foldable mirrors
• Rear windscreen with intermittent wiper
• Tinted glass

• Rain sensing windscreen wipers
• Front and rear wheels: 16 inch alloy rims ; width: 6.0 inches
• Space saver steel spare wheel
• Plastic body, plastic body

• Five seats configured 2+3
• Six speakers
• Audio system with digital media card reader and CD player that reads MP3 CDs ; radio receives AM/FM and RDS
• Steering wheel mounted remote audio controls
• 12v power outlet located in cargo section, front section and rear section
• Front and rear reading lights
• Load area light
• Driver and passenger vanity mirror
• Analogue dashboard
• Service interval indicator
• Tachometer
• External temperature
• Computer includes average speed, average fuel consumption, instantaneous fuel consumption and range for remaining fuel

• Alloy look gearknob
• Load restraint
• Central door locking: Operated by card key Includes dead bolt
• Cloth and leather seat upholstery
• Centre armrest between front seats
• Centre armrest between rear seats
• Driver seat: sports type adjustable height with seat back table, passenger seat: sports type with seat back table
• Asymmetrically folding rear seats: bench type with space for three people; with zero electric adjustments and reach adjustment
• Alloy & leather multi-function steering wheel with tilt adjustment
• Refrigerated storage compartment in glove compartment cooled by air conditioning outlet
• Storage compartment under passenger seat
• Cup holders for front seats and rear seats
• Ventilation system with digital controls and air filter

• Automatic air conditioning with fully automated climate control and one climate control zone
• Rear view mirror
• Front electric windows with one-touch on one window, rear electric windows
• Satellite navigation system with colour, 5.0 inch display, touch screen, 3D and voice, maps updated via SD Card and traffic information
• Floor console
• Automatic smart card/key includes central locking
• Fixed storage box in the boot
• Front hinged drivers door, rear door on drivers side, front passenger door and rear door on passenger side
• Bluetooth connection
• Lifting gate rear door
• Privacy glass on the rear window and on the rear side windows
• Connections for iPod, USB and auxiliary audio devices
• Multi-function display screen

• Two disc brakes including two ventilated discs
• ABS
• Rear radar-type parking distance sensors
• Electronic traction control
• Halogen headlights
• Headlight controlsystems: dusk sensor and height adjustment

• Front and rear side curtain airbags
• Drivers airbag, passengers airbag with de-activation switch
• Front side airbag
• Two head restraints on front seats with height adjustment, three head restraints on rear seats with height adjustment
• Height adjustable seat belt with pre-tensioners on drivers seat and front passenger seat

• Seat belt on driver side rear seat, seat belt on passenger side rear seat, 3-point seat belt on central rear seat
• Stability controlsystem
• Electronic brake distribution
• Brake assist system
• Isofix preparation

• Cruise control
• Front-wheel drive
• 1,461 cc 1.5 litres in-line 4 engine with 76.0 mm bore, 80.5 mm stroke, 15.2 compression ratio, overhead cam and two valves per cylinder
• Turbo-charger
• Emissions: EU5 compliant, 110 g/km CO2 (min), 110 g/km CO2 (max), 0.380 g/km carbon monoxide, 0.188 g/km HC+NOx, 0.166 g/km NOx, 0.000 g/km particulate matter and 72 dB noise level
• Fuel system: common rail diesel

• Primary fuel type: diesel
• Performance: maximum speed 104 mph, 168 km/h acceleration 12.8 seconds (0-100 km/h)
• Power: (from primary fuel) 66 kW , 90 HP EEC @ 4,000 rpm; , 200 Nm @ 1,750 rpm
• Type speed proportional power steering
• Independent strut front suspension with anti-roll bar and coil springs, semi-independent torsion beam rear suspension with coil springs
• Manual five-speed transmission with shift lever on floor, 3.727:1 first gear ratio, 2.048:1 second gear ratio, 1.321:1 third gear ratio, 0.971:1 fourth gear ratio, 0.756:1 fifth gear ratio and 3.545:1 reverse gear ratio manual

• Traffic light A-G coding: efficiency label B
• Main servicerequired after 20,117 km, 12,500 miles, 12 months
• Particle filter system
• Fuel consumption: 5.0 l/100km (urban), 3.7 l/100km (country/highway), 4.2 l/100km (combined), 47 mpg (urban US), 64 mpg (country/highway US), 56 mpg (combined US), 20.0 km/l (urban), 27.0 km/l (country/highway), 23.8 km/l (combined), 57 mpg (urban UK), 76 mpg (country/highway UK), 67 mpg (combined UK) ; Range 1,095 km, 680 miles ; Standard: ECE 99/100
• Powertrain: internal combustion engine
• Speed limiter

• Steering wheel mounted remote audio controls
• ABS
• Cruise control
• Rear radar-type parking distance sensors
• Electronic traction control
• Front fog lights
• Central door locking: Operated by card key Includes dead bolt
• Drivers airbag, passengers airbag with de-activation switch

• Front side airbag
• Centre armrest between front seats
• Centre armrest between rear seats
• Type speed proportional power steering
• Cup holders for front seats and rear seats
• Automatic air conditioning with fully automated climate control and one climate control zone
• Front electric windows with one-touch on one window, rear electric windows
• Satellite navigation system with colour, 5.0 inch display, touch screen, 3D and voice, maps updated via SD Card and traffic information

• Stability controlsystem
• Electronic brake distribution
• Brake assist system
• Isofix preparation
• Bluetooth connection
• Privacy glass on the rear window and on the rear side windows
• Connections for iPod, USB and auxiliary audio devices

VED Band and CO₂
